Concrete Equipment and CTB Plants

PORTABLE 12YD ROSS BANDIT CONCRETE BATCH PLANT

This Bandit 12 plant was purchased new by the owner and was used for the owner's own projects, not a primary ready mix operation. The plant ran last fall when it batched concrete for the owner's new building and at that time the cement silo was emptied. The owner is a sand-gravel producer and that is his primary business. The plant is like new since it has been used for mostly small projects......... Portable 2000 Ross bandit 12YD Concrete batch plant.... 200 yards per hour..... Portable complete with aggregate storage bin with weigh batcher, cement storage bin with weigh batcher, truck charging chute, 30" 15hp aggregate transfer conveyor, 7 1/2hp air system, 3" water system , silo dust collector with batcher, truck dust collection shroud, manual 74B plant controls in stationary wood building, includes 2 Cardinal digital weigh indicators. Included in price plant will be taken down and made road ready.

More Photos:

REXCON LOGO 5 PORTABLE CONCRETE BATCH PLANT

Rexcon Logo 5 Portable Concrete Batch Plant. This plant is rated at 5cy per drop and 120 plus yards per hour. Unit is completely portable, fold down for transport, has digital scales and digital water meter. 3 bin aggregate system, cement silo is an in frame 200bbl (30ton) with powder weigh hopper. Flyash silo is a (25ton) with auger. This plant a 24" x 30' charge belt, fully automated Ace CO computer control system, plant is fully refurbished with all new valves, conveyor belting, aerators, air lines, electrical, dust collector bags, new air cylinder and air compressor. Bin and radial stacker be included. Plant still in use and erected.

More Photos:

2013 - 750 TPH PUGMILL SYSTEMS CTB Plant

Description 1236 FEEDER BIN 12 YARD HOPPER AND 36” BELT: SELF RELIEVING FEEDER DESIGN, BIN EXTENSIONS, 3/16” X 1/16” 2-PLY BELT, 12” CROWNED HERRINGBONE GROOVED HEAD PULLEY, 12” WINGED TAIL PULLEY, 10 HP MOTOR (TEFC 230/460 3 PHASE 60 HZ), SHAFT MOUNT REDUCER, 12” TRAVEL SCREW TYPE TAKE-UPS, ADJUSTABLE GATE, MOUNTED ON COLUMNS, ELECTRIC VIBRATOR, UHMW LINER 3635 CHANNEL FRAME CONVEYOR 36” WIDE BELT 35’ LENGTH: 3/16” X 1/16” 2-PLY BELT, 14” CROWNED HERRINGBONE GROOVED HEAD PULLEY, 12” WINGED TAIL PULLEY, 20 DEGREE TROUGHING IDLERS, SCREW TYPE TAKE-UPS WITH 18” TRAVEL, 15 HP (TEFC 230/460 3 PHASE 60 HZ) MOTOR, SHAFT MOUNT REDUCER WITH BUILT IN BACKSTOP BELT SCALE FOR COORDINATING CEMENT FEEDER, FLYASH, AND WATER SYSTEMS WATER PUMP 5 HP, VARIABLE SPEED CONTROLLER, AND METER 750 BT PUGMILL WITH TWIN-SHAFT TWIN-DRIVE- INLET END DRIVE; 2 50 HP MOTORS (TEFC 230/460 3 PHASE 60HZ), SHAFT MOUNT REDUCERS, TIMING GEARS AND GEAR HOUSING, LIQUID SPRAY BAR WITH 2” VALVE, HINGED COVER OVER MIXING CHAMBER, RECEIVING HOPPER, CONTOUR LINER (AR235 PLATE), HI-CHROME PADDLE TIPS, REVERSIBLE FOR WEAR, BELT GUARDS, BOLT ON DISCHARGE END PLATE, WIDE FLANGE BEAM BASE FRAME, SUPPORT STRUCTURE, WALKWAYS 3675 TRUSS FRAME CONVEYOR 36” WIDE BELT 75’ LENGTH, FROM PUGMILL TO DIVERTER CHUTE: 3/16” X 1/16” 2-PLY BELT, 18” CROWNED HERRINGBONE GROOVED HEAD PULLEY, 16” WINGED TAIL PULLEY, 35 DEGREE TROUGHING ILDERS, SCREW TYPE TAKE-UPS WITH 18” TRAVEL, 30HP (TEFC 230/460 3 PHASE 60 HZ) MOTOR, SHAFT MOUNT REDUCER WITH BUILT IN BACKSTOP, SKIRTED RECEIVING HOPPER, LOWER AND MID SUPPORTS, UPPER SUPPORT BRACKETS, CONVEYOR COVERS PANTS LEG DIVERTER CHUTE: AIR CYLINDER AND SOLENOID VALVE, DISCHARGE TO SURGE HOPPER OR DIVERT TO GROUND 10 YD. SURGE HOPPER: ¼” PLATE HOPPER, AIR OPERATED CLAM GATES, STRUCTURAL STEEL SUPPORTS, HANDRAILS AND LADDER, 12’ DRIVE THRU CLEARANCE, UHMW LINERS, AIR VIBRATOR 2 FEEDING SYSTEMS AND WEIGH PODS WITH LOSS-IN WEIGHT CONTROLLERS FOR CEMENT AND FLYASH 12” SCREW CONVEYOR FROM FLYASH SILO TO PUGMILL AIR COMPRESSOR 6’X6’ CONTROL HOUSE AND CONTROL SYSTEM: CONTROL CONSOLE, MAIN DISCONNET, CIRCUIT BREAKERS, MOTOR STARTERS, WIRING SYSTEM WITH PLUG CONNECTORS, PLC FOR SEQUENTIAL STARTING AND STOPPING, TOUCH SCREEN, DISPLAYS TARGET AND ACTUAL INGREDIENT PERCENTAGES, STORES UP TO 8 RECIPES, SELECTABLE FROM FRONT SCREEN, WATER RATIO MAY BE CHANGED ‘ON THE FLY’, VARIABLE SPEED DRIVES FOR BOTH ROTARY VANE FEEDERS AND FEEDER BIN CONVEYOR, AIR CONDITIONING......... PRICE INCLUDES DELIVERY TO ANYWHERE IN CONTINENTAL USA.

More Photos:

PORTABLE 550TPH CTB - SOIL CEMENT PLANT

Portable CTB - Soil Cement Plant (1) 2- Bin feeder bin 32 tons each, 30" feeder belt, 32" collectors belt make: Caterpillar, all portable (1) Pug mixer with 4X8 scalper screen, 36" Superior belt with Fast Weigh belt scale. Dakota 600 ton per hr. pug 75 H.P. All portable (1) 40 ton cement silo with Vane feeder V.F.D. drive, 12" auger to plant and weigh scale cells on 4 legs. (1) 36" Superior conveyor with fast weigh scale. Pug to load-out bins (1) 30 ton load- out bin (1) 42" Reuter load-out conveyor (1) Control room with switch gear and plant controls. Belt scale read-outs and printers. Air conditioned and portable (1) 325 K.W. Cat generator- runs all plant functions (1) Container with all plant accessories, safety equipment and misc. parts (2) 42 ft. flatbed equipment trailers that move load- out bin, conveyors and silo foundation...........................PLANT WAS RECENTLY USED FOR A FEDERAL JOB LINING SEDIMENT PONDS..........................APPLICATION WAS, SOIL WAS SCREENED THEN PUT IN BINS WHERE 7% CEMENT WAS ADDED THEN IT WAS LAID AND COMPACTED. PLANT ON GROUND AND LINED UP READY FOR TRANSPORT.............................UNIT IS DOING A JOB AND WONT BE AVAILABLE UNTIL JOB FINISHED AROUND SPRING 2017.

More Photos:

4 YARD TURBIN CENTRAL MIX PLANT

4 Yard Turbin Mixer 150 hp Model 450 Agg Weigh Bin 8x12 Load Cells Agg Bin with 8 Hoppers with 2' Gates Cement Silo with Partition for two products 11'9 dia x 27'with Hi and Lo Bindicators Cement Silo Baghouse Cement Silo support Structure 10x10 Feed Bin Two, Screw Conveyors 8''x30 Two 10'' x25' Screws Two, 24''x65' Deep Trough Feed Conveyors Air Compressor ALKON Controls Control Monitors All Books and Manuals Extra Motors . ****(This central mix concrete plant spent its entire life inside a building and id in very nice condition. The plant is down on the ground ready to load. There is a extensive lot of spare parts that is included in the sale price. Please see the below.)**** Spare 150 HP motor. Rebuilt and still on the skid. Spare transmission. Rebuilt and still on the skid. Spare lubricator for the transmission. Spare arms and shoes. Spare cylinder for the gates. Many other small parts and rebuild kits. The liner was just replaced about 3 months before we took it out. Belts were recently replaced on both conveyors.

PORTABLE CONECO ALL-PRO SUPER 12 YDR Plant

CONECO ALL-PRO SUPER S/N C-4170 NEW 1/1993 HOURS: 12 CY BATCH -22 SECONDS 48" DISCHARGE BELTS 3" CONECO WATER METER 480 GALLON HOLDING TANK 2" TEMPER CONECO WATER METER 620/516 BB SPLIT CEMENT SILO DUST COLLECTOR SYSTEM 3 - 36" CONVEYORS (1 - CONECO, 2 - PEERLESS) PEERLESS 3 X 6 VIBRATING SCREEN (SAND) 1- 20' STORAGE CONTAINER 1- 20' CONTROL CONTAINER (STACKED) W/STAIRWAY 2 - 50,000 GALLON FRAC TANKS ERIE STRAYER 12 CY TILTING MIXER 2-75 HP DRUM DRIVE MOTORS HEAVY DUTY PLANETARY GEAR REDUCERS 60 HP HYDRAULIC POWER UNIT WITH TILT SPEED CONTROL ON MIXER FRAME AR 400 BLADES AND BUCKETS W/AR 400 WEAR BARS NOSE PLUG RELINED 2012 (STEEL LINERS) CATERPILLER 2406B 365 KW GENSET WITH FUEL TANK

750 BBL Stationary Silo

Cement Silo Fuffer Pads, Air Chop Gate, Electrical Box 750 BBL Stationary C & W Baghouse (SN # 10211) with blower and 20 hp motor

More Photos:

PORTABLE CONCRETE SILO

700 BBL. Lime / Mineral / Cement Silo Portable Motorized Vane feeder with elephant trunk discharge attachment Equipped with Ground Frame and Load Cells for negative or decumulative weigh-out of materials.

More Photos:

2 CONCRTE STORAGE SILOS

Two Cement Silos w/Auger System To Blend and Load into Trucks. ----One Silo approximately 35 Ft. high w/Bag House ----One Silo approximately 29 Ft. high w/Bag House ----Motors run on 220/440 Volts ----Mfg.---1996 (approx.) Lift-Truck Capacity Up 100,000# (50 Ton) Gantry Capacity Up To 800,000# (400 Ton) This Machine is in Very Good working Order!--Still is under Power .
